Some programs get very upset when their files can’t be chown’d to their own special user. How can you reconcile this when you want the program to write to a location where only one user can own files?

The Problem

I recently wanted to try out Obsidian LiveSync on my “homelab” (read: mini PC which connects to a NAS SMB mount). I ran into a problem though: CouchDB, which LiveSync uses, requires that files written to the disk be owned by a user called couchdb! With my setup, only brendan can own files on Brendan’s SMB share. I needed a solution.

Enter QCOW2 files! Instead of hosting CouchDB’s files in a folder on my NAS, I can just make a virtual filesystem inside a file on the NAS! Then I can mount the filesystem and read/write with whichever user I please.

Create and Test the QCOW2 File

1. Install qemu.
2. Make your QCOW2 file on the NAS via $ qemu-img create -f qcow2 /mnt/nas/my_drive.qcow2 100G. You’ve got to specify a max size, but don’t worry too much. After formatting, my max-100G file only takes up 15MB.
3. Mount the QCOW2 file.
   1. Enable the Linux NBD (Network Block Device) module: # modprobe nbd max_part=8
      • You can change the max number of partitions if you like. On my Arch system, modinfo reports that the default is 16.
   2. Connect to the QCOW2 file as a block device: # qemu-nbd --connect=/dev/nbd0 /mnt/nas/my_drive.qcow2
4. Partition your file: # echo 'type=83' | sfdisk /dev/nbd0
   • You can also use fdisk or your favorite partitioning software.
   • Type 83 is the generic Linux partition type. Feel free to change. See echo "l" | fdisk <some disk>
5. Make the filesystem. I chose ext4 here. # mkfs.ext4 /dev/nbd0p1
6. Mount your filesystem. # mount /dev/nbd0p1 /mnt/nas-qcow2-file
7. Verify that you can write as an arbitrary user to your filesystem: echo 'test' > /mnt/nas-qcow2-file/test-9999.txt && chown 9999:9999 /mnt/nas-qcow2-file/test-9999.txt && ls -l /mnt/nas-qcow2-file/test-9999.txt
   • You’re looking for output similar to -rw-r--r-- 1 9999 9999 5 Aug 24 17:25 /mnt/nas-qcow2-file/test-9999.txt. Note that the owner is 9999.

Automatically Mount the File

1. Make your mount point: # mkdir /mnt/nas-qcow2-file

   • If you want your mount point to only be writable if the qcow file is mounted, use chattr: # chattr +i /mnt/nas-qcow2-file. I recommend this.

2. Make a script to execute the above steps. I stored mine in /usr/bin/mount-qcow2:

    1#!/bin/sh
    2
    3# Abort if any command fails
    4set -e
    5
    6# The QCOW2 file to mount
    7readonly QCOW_TO_MOUNT="/mnt/nas/my_drive.qcow2"
    8
    9# Optional: if you can guarantee /mnt/nas/my_drive.qcow2 is available, remove this block.
   10# Wait until the qcow file is available
   11while [ ! -e "$QCOW_TO_MOUNT" ]; do
   12  echo "Could not find qcow2 file at '$QCOW_TO_MOUNT'. Waiting 10 seconds..."
   13  sleep 10
   14done
   15
   16# For some reason, this script could not find modprobe when run by cron.
   17# modprobe worked just fine when running otherwise. As a band-aid fix,
   18# specify the full path.
   19/usr/sbin/modprobe nbd max_part=8
   20
   21qemu-nbd --connect=/dev/nbd0 "$QCOW_TO_MOUNT"
   22mount /dev/nbd0p1 /mnt/nas-qcow2-file

3. Test your script: # /usr/bin/mount-qcow2

   • Disconnecting from the file might be useful here for testing: # umount /mnt/nas-qcow2-file && qemu-nbd --disconnect /dev/nbd0

4. Set your script to run at startup. I did this via cron: # echo "@reboot root /usr/bin/mount-qcow2 > /var/log/mount-qcow2 2>&1" > /etc/cron.d/mount-qcow2

   • Note that I had an issue when running this script via cron: modprobe could not be found! I’m sure some Unix guru knows exactly why, but my band-aid fix was to specify the absolute path of the executable at /usr/sbin/modprobe.

5. Reboot and verify you can write to your mounted file!

Sources:

1. How to make a QCOW2 file
2. How to mount a QCOW2 file
3. sfdisk one-liner
4. Chattr on mount point idea
